Janisol Arte 66 lift-and-slide door

Delicate partitions between large glass elements allow the interior and exterior to merge elegantly, transforming living spaces into viewing platforms. Leaf sizes of up to 3000 mm (W) x 2600 mm (H) with leaf weights of up to 400 kg appear to float directly above the floor, yet are easy to operate. We work with different opening schemes – A, C, D and K, which vary in the number of moving leaves. This enables a flexible response to varying requirements in terms of functionality, appearance and spatial conditions.

Thanks to its outstanding performance in resisting driving rain and wind loads, this lift-and-slide door is ideally suited to spacious living areas and openings onto terraces or balconies. These opening elements provide elegant transparency to the outside in public areas such as offices, hotels or clinics, and the door is available with a barrier-free threshold for wheelchair access.

System description

Materials / surface finish

  • Strip-galvanised steel, suitable for powder coating or stove-enamelling

Element types

  • Lift-and-slide door
  • Scheme A with one movable sash
  • Schemes C, D and K with two movable sashes

Performance characteristics

Equipment

  • Hardware up to 400 kg per sash
  • Sash width up to 3000 mm, sash height up to 2600 mm
  • Other configurations on request

Special technical features

  • Barrier-free threshold possible
  • Insulating glass 24 – 46 mm
  • Installation depth of sliding and fixed sash 185 mm
  • Face width of centre section 55 mm
  • XL version of the fixed panel possible for increased natural light

Product details

Test certificates

  • CE marking according to the EN 14351-1 product standard
  • Water tightness up to class 8A (450 Pa)
  • Air permeability up to class 4 (600 Pa)
  • Resistance to wind load up to class C3/B3 (1200 Pa)
  • Airborne sound insulation up to Rw 40 dB (-2; -7)
